Question 1

Refer to the exhibit.

The following must be considered:

* SW1 is fully configured for all traffic

* The SW4 and SW9 links to SW1 have been configured

* The SW4 interface Gi0/1 and Gi0/0 on SW9 have been configured

* The remaining switches have had all VLANs added to their VLAN database

Which configuration establishes a successful ping from PC2 to PC7 without interruption to traffic flow between other PCs?

Options :

A :

B :

C :

D :

Answer: C

Question 2

Which function does an SNMP agent perform?

Options :

A : it sends information about MIB variables in response to requests from the NMS

B : it requests information from remote network nodes about catastrophic system events.

C : it manages routing between Layer 3 devices in a network

D : it coordinates user authentication between a network device and a TACACS+ or RADIUS server

Answer: A

Question 3

What is a DHCP client?

Options :

A : a workstation that requests a domain name associated with its IP address

B : a host that is configured to request an IP address automatically

C : a server that dynamically assigns IP addresses to hosts.

D : a router that statically assigns IP addresses to hosts.

Answer: B

Question 4

Which action is taken by a switch port enabled for PoE power classification override?

Options :

A : When a powered device begins drawing power from a PoE switch port a syslog message is generated

B : As power usage on a PoE switch port is checked data flow to the connected device is temporarily paused

C : If a switch determines that a device is using less than the minimum configured power it assumes the device has failed and disconnects

D : Should a monitored port exceeds the maximum administrative value for power, the port is shutdown and err-disabled

Answer: D

Question 5

Which statement about Link Aggregation when implemented on a Cisco Wireless LAN Controller is true?

Options :

A : To pass client traffic two or more ports must be configured.

B : The EtherChannel must be configured in 'mode active'

C : When enabled the WLC bandwidth drops to 500 Mbps

D : One functional physical port is needed to pass client traffic

Answer: D
